The vibrating rod level switch is the perfect solution for single point level switching in free flowing solids across a wide density range, from fine powders to grains. A single rod design provides the solution to tuning forks which may become blocked or bridged.
FEATURES
- Reliable point level detection in a variety of dry solid applications.
SPECIFICATION
| Output |
| One SPDT control relay, 8 A at 250 Vac |
| Process Media |
| Free flowing dry products, ∅ < 10 mm, low density (100 to 250 kg/m3) to very high density (up to 2500 kg/m3) |
| Process Connection |
| 1.5-in. NPT or BSP thread for tank mounting |
| Process Wetted Material |
| 316 stainless steel |
| Housing Material |
| Aluminum alloy, powder paint coated |
| Cable Glands |
| Two 0.5-in. NPT (NPT models) or two Pg16 (BSPT models) conduit entries. Ingress protection rating is IP67 |
| Operating Temperature |
| –20 °C to +110 °C (Standard models). –20 °C to +160 °C (High temperature models). |
| Operating Pressure |
| 10 bar maximum |
| Power Supply |
| 20 to 255 Vac (50/60Hz) / 20 to 255 Vdc, or 20 to 250 Vac (50/60Hz) / 20 to 50 Vdc |
